General Specifications
Socket
LGA 1700
Form Factor
Micro ATX
Chipset
Intel B760
Weight
Unknown
Max Memory
256 GB
Memory Type
DDR5
Memory Slots
4
Colors
BLACK
GREY
Lighting
None
PCIe Slots
1 x PCIe 5.0 x16
2 x PCIe 4.0 x1
1 x PCIe 4.0 x4
M.2 Slots
M 2242/2260/2280 PCIe 4.0 x4
M 2242/2260/2280 PCIe 4.0 x4
M 2242/2260/2280 PCIe 3.0 x2
SATA 6Gb/s
4
SATA 3Gb/s
0
U.2 Ports
0
Onboard Ethernet
Realtek 1 Gb/s
WiFi
WiFi 6 Bluetooth 5.3
USB 2.0
2
USB 3.2 Gen 1
2
USB 3.2 Gen 2
2
USB 3.2 Gen 2x2
0
USB 4.0
0
USB 4 80Gbps
Unknown
CPU Fan Headers
1
Case Fan Headers
3
Pump Headers
1
CPU Optional Fan Headers
1
ARGB 5V Headers
3
RGB 12V Headers
Unknown
Power Button Header
Yes
Reset Button Header
Yes
Power LED Header
Yes
HDD LED Header
Yes
Temperature Sensor Headers
Unknown
Thunderbolt Headers
Unknown
COM Port Headers
1
Main Power
24-pin
CPU Power
8-pin
ECC Support
No
RAID Support
Yes
Back-Connect Connectors
No
BIOS Flashback
No
Clear CMOS Button
No
Audio Chipset
Realtek
Audio Channels
7.1
Back Panel Ports
2 x USB 10Gbps ports
4 x USB 5Gbps ports
1 x DisplayPort
1 x HDMI port
1 x Wi-Fi Module
1 x Realtek 1Gb Ethernet port
3 x Audio jacks
Display Outputs
Unknown
Product Information
Manufacturer
ASUS
Series
MAX GAMING
Variant
B760M WIFI
Release Year
2026
Manufacturer Color
Black
UPC
199291026575
EAN
0199291026575
Part Numbers
B760M MAX GAMING WIFI
BuildCores ID
6vo7jzuim
Motherboard
ASUS B760M MAX GAMING WIFI
SocketLGA 1700
Form FactorMicro ATX
ChipsetIntel B760
